Product Details:
Payment & Shipping Terms:
|
Height: | 6M - 15M | Wind Speed: | 160km/h |
---|---|---|---|
Material: | Steel Q235 | Torlance: | +-2% |
Shape: | Taper , Conical, Octagonal | Finishing: | Hot Dip Galvanized |
Arm: | No, Single Or Double | Type: | With Base Plate Install |
Highlight: | parking lot lighting poles,Square Light post |
Conical Octagonal Galvanized Parking Lot Light Pole Lam Pole for Square
Specification
name | Conical Octagonal Galvanized Parking Lot Light Pole Lam Pole for Square |
Type | Parking Lot Light Pole |
Shape | conical, hexagonal and octagonal |
Material | Usually Q345B/A572,minimum yield strength>=345n/mm2 Q235B/A36,minimum yield strength>=235n/mm2 As well as Hot rolled coil from Q460, ASTM573 GR65, GR50, SS400, SS490ST52 |
Tolerance of dimension | +-2% |
Design Load in Kg | 300~ 1000 Kg appliced to 50cm from the to pole |
Surface treatment | Hot dip galvanized Following ASTM A 123, Or powder coated. |
Standard | Octagonal Conical tapered column Certified by SIRIM QAS INTERNATIONAL. Approved by JABATAN KERJA RAYA MALAYSIA. Conforms to Standard: Pole design: BS EN 40 Material: BS EN 10025 S275 / JIS G3101 SS400 Welding: BS 5135 Galvanizing : BS 729 / ISO 1461 ASTM A 123 |
Parking Lot Light pole suit for | city square, wharf, stadium, Parking Lot, Road, Street, Garden, etc |
Option of Light pole | Height from 6m to 12m Flange mounted or Burial type |
Description
1. Material :SS400, Q235,A36 (yield strength: 235Pa 24kg/mm2 Tensile Strength: 375-460Pa 38-47kg/mm2
(Other Materials are Available as required)
2. Hot Dip Galvanized (≥86um)
3. Any Color Polyester Powder Coated (≥100 um)
4. Taper Conical, Octagonal, Polygon Section
5. With demounted bracket design,easy loaded,install and maintenance
6. Theftproof slide lock
7. Category: Street lighting pole, Garden Lighting pole Solar Street lighting pole, High Mast,highmast light poles,
- Material preparation
- Bending
- Welding
- Repair and grinding
- Reforming
- Flushing
- Fix bottom plate
- Welding bottom plate
- Opening door
- Welding door strip, electric strip, and locking
- Bending arm
- Hot dip galvanization
- Plastic powder painted
- Inspection
- Delivery
Quality Control Management
Our company processes professional physical and chemical inspection lab and is equipped with X-ray detection system, ultrasonic detection system, screen display universal testing machine, photoelectric emission spectrum analyzer, as well as carbon and sulfur microcomputer analyzer etc.
Meanwhile, it has formed a scientific and strict quality management system, which effectively and strictly guarantees the quality control of products form raw material to finished products.
The rate of pass of street light pole is 98%. Smooth installation and complete match. The rate of customer satisfaction is 95%,
Terms and Conditions
1. Price Term: EXW, FOB, CFR or CIF.
Ø EXW: Poles Cost
Ø FOB : Pole Cost + Land Transportation + Fee on Port
Ø CFR : Pole Cost + Land Transportation + Fee on Port + Sea Freight
Ø C I F : Pole Cost + Land Transportation + Fee on Port + Sea Freight + Insurance.
2. MOQ: One 40FT Container.
3. Payment Term: Typically 30% by T/T as a deposit, balance by T/T or L/C at sight before shipment. Other
payment way can be negotiated.
4. Delivery Time: 15 working days per container after PI/drawing/ prepayment confirmed.
5. Package: Normally wrapped by plastic bags or burlap cloth at the top and bottom, or according to clients’
requirement.
Company Information
Through the efforts of the company staff, the support and cooperation from all over the world. Baojuhe's steel poles have been exported to the Philippines, Malaysia, Australia, America, Africa, Latin America, Panama, Suriname, Costa Rica, Colombia, Jordan, Nigeria, etc. We have good export experience and with 1 container export to World per day on average.
